Figure 3-4 Key module 3x3
3.4.4 Key module 1x3
This is a passive key module with 3 illuminated short-stroke keys with replaceable key caps.
The connection to the MCP is made via one of the active modules "Key module 3x3" (Page 24),
"Key module 3x4" (Page 24) and "Key module 3x5" (Page 23). The key module can be installed
in both the horizontal and vertical installation position.

Figure 3-5 Key module x.1 1x3

Figure 3-6 Key module x.2 1x3
3.4.5 Key module 1x2
This is a passive key module with 2 illuminated short-stroke keys with replaceable key caps.
The connection to the MCP is made via one of the active modules "Key module 3x3" (Page 24),
"Key module 3x4" (Page 24) and "Key module 3x5" (Page 23). The key module can be installed
in both the horizontal and vertical installation position.

Figure 3-7 Key module x.1 1x2

Figure 3-8 Key module x.2 1x2
