5.2 Input images
The speci󹪝cations for assigning input and output bytes listed in the tables can be changed in the
PLC via parameter assignment.
Note
The following applies in respect of the process input and output images in the tables: n is
de󹪝ned by means of FB1 parameters in OB100 of the PLC.
Base
Slot Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Base EB n + 0 KT-IN8
X515.8
KT-IN7
X515.7
KT-IN6
X515.6
KT-IN5
X515.5
KT-IN4
X515.4
KT-IN3
X515.3
KT-IN2
X515.2
KT-IN1
X515.1
EB n + 1 KT-IN16
X516.8
KT-IN15
X516.7
KT-IN14
X516.6
KT-IN13
X516.5
KT-IN12
X516.4
KT-IN11
X516.3
KT-IN10
X516.2
KT-IN9
X516.1
EB n + 2 Spindle override
E (2
4
) D (2
3
) C (2
2
) B (2
1
) A (2
0
)
EB n + 3 Feed override
E (2
4
) D (2
3
) C (2
2
) B (2
1
) A (2
0
)
EB n + 4 Keyswitch
Position 3 Position 2 Position 1 Position 0
EB n + 5
Key modules
Slot Byte *) Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Key module 1 EB n + 0 Key module 1
Key7 Key6 Key5 Key4 Key3 Key2 Key1 Key0
EB n + 1 Key module 1
- Key14 Key13 Key12 Key11 Key10 Key9 Key8
EB n + 2 Key module 1.1
- - - - - Key18 Key17 Key16
EB n + 3 Key module 1.2
- - - - Key26 Key25 Key24
Connecting
5.2 Input images
ONE MCP Part 1: MCP xxxx
Equipment Manual, 07/2020, A5E50324729B AA 45
