Figure 3-9 Example of spindle override
Note
The connection to the MCP is made via X30/X31.
X30 Spindle override
X31 Feedrate override
3.7 Electronic handwheels
Figure 3-10 Handwheel
Operator control and display elements
3.7 Electronic handwheels
ONE MCP Part 1: MCP xxxx
Equipment Manual, 07/2020, A5E50324729B AA 27
