Siemens SIPROTEC 7RW80 User Manual

Mounting and Commissioning
3.2 Checking Connections
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
156
USB Interface
The USB interface can be used to establish a connection between the protection device and your PC. For the
communication, the Microsoft Windows USB driver is used which is installed together with DIGSI (as of version
V4.82). The interface is installed as a virtual serial COM port. We recommend the use of standard USB cables
with a maximum length of 5 m/16 ft.
Table 3-2 Assignment of the USB socket
Connections at port A
If the interface is used for communication with the device, the data connection is to be checked.
Table 3-3 Assignment of the port A socket
Pin No. 1 2 3 4 Housing
USB VBUS
(unused)
D- D+ GND Shield
Pin No. Ethernet interface
1Tx+
2Tx-
3Rx+
4—
5—
6Rx-
7—
8—
