Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
209
1)
The converter requires an operating voltage of DC 24 V. If the available operating voltage is > DC 24 V the
additional power supply 7XV5810–0BA00 is required.
Additional information for additional ports (bottom side of device, rear, port B) Supple-
ment
Profibus DP Slave, electrical RS485 + L 0 A
Profibus DP Slave, 820 nm, optical, double ring, ST-connector + L 0 B
Modbus, electrical RS485 + L 0 D
Modbus, optical 820 nm, ST–connector + L 0 E
DNP3.0, electrical RS485 + L 0 G
DNP3.0, optical 820 nm, ST–connector + L 0 H
IEC 61850 100Mbit Ethernet, electrical, double, RJ45 connector + L 0 R
IEC 61850 100Mbit Ethernet optical, double, LC duplex connector + L 0 S
Converter Order Number Use
SIEMENS OLM
1)
6GK1502–2CB10 For single ring
SIEMENS OLM
1)
6GK1502–3CB10 For double ring
Port A (bottom side of device, front) Pos. 12
Not installed 0
with Ethernet port (DIGSI port, not IEC61850), RJ45 connector 6
Measuring/Fault Recording Pos. 13
With fault recording and min/max values for voltage 1
