Siemens SIPROTEC 7RW80 User Manual

Appendix
A.7 Settings
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
226
213 VT Connect. 3ph P.System Data 1 Van, Vbn, Vcn
Vab, Vbc, VGnd
Vab, Vbc, VSyn
Vab, Vbc
Vph-g, VSyn
Vab, Vbc, Vx
Van, Vbn, Vcn VT Connection, three-phase
214 Rated Frequency P.System Data 1 50 Hz
60 Hz
50 Hz Rated Frequency
220 Threshold BI 1 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 1
221 Threshold BI 2 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 2
222 Threshold BI 3 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 3
223 Threshold BI 4 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 4
224 Threshold BI 5 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 5
225 Threshold BI 6 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 6
226 Threshold BI 7 P.System Data 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 7
232 VXnom PRIMARY P.System Data 1 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage X
233 VXnom SECONDARY P.System Data 1 100 .. 225 V 100 V Rated Secondary Voltage X
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting Group
401 WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
402 WAVEFORM DATA Osc. Fault Rec. Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
403 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform Capture
Record
404 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform Prior to Trigger
405 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device, General Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
611 Spont. FltDisp. Device, General YES
NO
NO Spontaneous display of flt.annunci-
ations
614A OP. QUANTITY 59 P.System Data 1 Vphph
Vph-n
V1
V2
Vphph Opera. Quantity for 59 Overvolt.
Prot.
615A OP. QUANTITY 27 P.System Data 1 V1
Vphph
Vph-n
V1 Opera. Quantity for 27 Undervolt.
Prot.
640 Start image DD Device, General image 1
image 2
image 3
image 4
image 1 Start image Default Display
1101 FullScaleVolt. P.System Data 2 0.10 .. 800.00 kV 20.00 kV Measurem:FullScaleVolt-
age(Equipm.rating)
4301 FCT 24 V/f 24 V/f Overflux OFF
ON
OFF 24 Overexcit. Protection (Volt/Hertz)
4302 24-1 PICKUP 24 V/f Overflux 1.00 .. 1.20 1.10 24-1 V/f Pickup
4303 24-1 DELAY 24 V/f Overflux 0.00 .. 60.00 sec; ∞ 10.00 sec 24-1 V/f Time Delay
Addr. Parameter Function Setting Options Default Setting Comments
