Siemens SIPROTEC 7RW80 User Manual

Appendix
A.7 Settings
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
227
4304 24-2 PICKUP 24 V/f Overflux 1.00 .. 1.40 1.40 24-2 V/f Pickup
4305 24-2 DELAY 24 V/f Overflux 0.00 .. 60.00 sec; ∞ 1.00 sec 24-2 V/f Time Delay
4306 24-t(V/f=1.05) 24 V/f Overflux 0 .. 20000 sec 20000 sec 24 V/f = 1.05 Time Delay
4307 24-t(V/f=1.10) 24 V/f Overflux 0 .. 20000 sec 6000 sec 24 V/f = 1.10 Time Delay
4308 24-t(V/f=1.15) 24 V/f Overflux 0 .. 20000 sec 240 sec 24 V/f = 1.15 Time Delay
4309 24-t(V/f=1.20) 24 V/f Overflux 0 .. 20000 sec 60 sec 24 V/f = 1.20 Time Delay
4310 24-t(V/f=1.25) 24 V/f Overflux 0 .. 20000 sec 30 sec 24 V/f = 1.25 Time Delay
4311 24-t(V/f=1.30) 24 V/f Overflux 0 .. 20000 sec 19 sec 24 V/f = 1.30 Time Delay
4312 24-t(V/f=1.35) 24 V/f Overflux 0 .. 20000 sec 13 sec 24 V/f = 1.35 Time Delay
4313 24-t(V/f=1.40) 24 V/f Overflux 0 .. 20000 sec 10 sec 24 V/f = 1.40 Time Delay
4314 24 T COOL DOWN 24 V/f Overflux 0 .. 20000 sec 3600 sec 24 Time for Cooling Down
4601 VECTOR JUMP Vector Jump OFF
ON
OFF Jump of Voltage Vector
4602 DELTA PHI Vector Jump 2 .. 30 ° 10 ° Jump of Phasor DELTA PHI
4603 T DELTA PHI Vector Jump 0.00 .. 60.00 sec; ∞ 0.00 sec T DELTA PHI Time Delay
4604 T RESET Vector Jump 0.10 .. 60.00 sec; ∞ 5.00 sec Reset Time after Trip
4605A V MIN Vector Jump 10.0 .. 125.0 V 80.0 V Minimal Operation Voltage V MIN
4606A V MAX Vector Jump 10.0 .. 170.0 V 130.0 V Maximal Operation Voltage V MAX
4607A T BLOCK Vector Jump 0.00 .. 60.00 sec; ∞ 0.15 sec Time Delay of Blocking
5001 FCT 59 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 59 Overvoltage Protection
5002 59-1 PICKUP 27/59 O/U Volt. 20 .. 260 V 110 V 59-1 Pickup
5003 59-1 PICKUP 27/59 O/U Volt. 20 .. 150 V 110 V 59-1 Pickup
5004 59-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 0.50 sec 59-1 Time Delay
5005 59-2 PICKUP 27/59 O/U Volt. 20 .. 260 V 120 V 59-2 Pickup
5006 59-2 PICKUP 27/59 O/U Volt. 20 .. 150 V 120 V 59-2 Pickup
5007 59-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 0.50 sec 59-2 Time Delay
5009 59 Phases 27/59 O/U Volt. All phases
Largest phase
Largest phase Phases for 59
5015 59-1 PICKUP V2 27/59 O/U Volt. 2 .. 150 V 30 V 59-1 Pickup V2
5016 59-2 PICKUP V2 27/59 O/U Volt. 2 .. 150 V 50 V 59-2 Pickup V2
5017A 59-1 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-1 Dropout Ratio
5018A 59-2 DOUT RATIO 27/59 O/U Volt. 0.90 .. 0.99 0.95 59-2 Dropout Ratio
5019 59-1 PICKUP V1 27/59 O/U Volt. 20 .. 150 V 110 V 59-1 Pickup V1
5020 59-2 PICKUP V1 27/59 O/U Volt. 20 .. 150 V 120 V 59-2 Pickup V1
5030 59 Vp> 27/59 O/U Volt. 20 .. 260 V 110 V 59 Pickup Vp>
5031 59 Vp> 27/59 O/U Volt. 20 .. 150 V 110 V 59 Pickup Vp>
5032 59 Vp> V1 27/59 O/U Volt. 20 .. 150 V 110 V 59 Pickup Vp> V1
5033 59 Vp> V2 27/59 O/U Volt. 2 .. 150 V 30 V 59 Pickup Vp> V2
5034 59 T Vp> 27/59 O/U Volt. 0.1 .. 5.0 sec 5.0 sec 59 T Vp> Time Delay
5035 Pickup - Time 27/59 O/U Volt. 1.00 .. 20.00 ; ∞
0.01 .. 999.00
Pickup - Time
5101 FCT 27 27/59 O/U Volt. OFF
ON
Alarm Only
OFF 27 Undervoltage Protection
5102 27-1 PICKUP 27/59 O/U Volt. 10 .. 210 V 75 V 27-1 Pickup
5103 27-1 PICKUP 27/59 O/U Volt. 10 .. 120 V 45 V 27-1 Pickup
5106 27-1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 1.50 sec 27-1 Time Delay
5109 27 Phases 27/59 O/U Volt. Smallest phase
All phases
All phases Phases for 27
5110 27-2 PICKUP 27/59 O/U Volt. 10 .. 210 V 70 V 27-2 Pickup
5111 27-2 PICKUP 27/59 O/U Volt. 10 .. 120 V 40 V 27-2 Pickup
5112 27-2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec; ∞ 0.50 sec 27-2 Time Delay
5113A 27-1 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-1 Dropout Ratio
5114A 27-2 DOUT RATIO 27/59 O/U Volt. 1.01 .. 3.00 1.20 27-2 Dropout Ratio
5130 27 Vp< 27/59 O/U Volt. 10 .. 210 V 75 V 27 Pickup Vp<
Addr. Parameter Function Setting Options Default Setting Comments
