Siemens SIPROTEC 7RW80 User Manual

Appendix
A.7 Settings
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
228
5131 27 Vp< 27/59 O/U Volt. 10 .. 120 V 45 V 27 Pickup Vp<
5132 27 T Vp< 27/59 O/U Volt. 0.1 .. 5.0 sec 1.0 sec 27 T Vp< Time Delay
5133 Pickup - Time 27/59 O/U Volt. 0.05 .. 1.00 ; 0
0.01 .. 999.00
Pickup - Time
5201 VT BROKEN WIRE Measurem.Superv ON
OFF
OFF VT broken wire supervision
5202 Σ V> Measurem.Superv 1.0 .. 100.0 V 8.0 V Threshold voltage sum
5203 Vph-ph max< Measurem.Superv 1.0 .. 100.0 V 16.0 V Maximum phase to phase voltage
5204 Vph-ph min< Measurem.Superv 1.0 .. 100.0 V 16.0 V Minimum phase to phase voltage
5205 Vph-ph max-min> Measurem.Superv 10.0 .. 200.0 V 16.0 V Symmetry phase to phase voltages
5208 T DELAY ALARM Measurem.Superv 0.00 .. 32.00 sec 1.25 sec Alarm delay time
5401 FCT 81 O/U 81 O/U Freq. OFF
ON
OFF 81 Over/Under Frequency Protec-
tion
5402 Vmin 81 O/U Freq. 10 .. 150 V 65 V Minimum required voltage for oper-
ation
5402 Vmin 81 O/U Freq. 20 .. 150 V 35 V Minimum required voltage for oper-
ation
5403 81-1 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 49.50 Hz 81-1 Pickup
5404 81-1 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 59.50 Hz 81-1 Pickup
5405 81-1 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 60.00 sec 81-1 Time Delay
5406 81-2 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 49.00 Hz 81-2 Pickup
5407 81-2 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 59.00 Hz 81-2 Pickup
5408 81-2 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 30.00 sec 81-2 Time Delay
5409 81-3 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 47.50 Hz 81-3 Pickup
5410 81-3 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 57.50 Hz 81-3 Pickup
5411 81-3 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 3.00 sec 81-3 Time delay
5412 81-4 PICKUP 81 O/U Freq. 40.00 .. 60.00 Hz 51.00 Hz 81-4 Pickup
5413 81-4 PICKUP 81 O/U Freq. 50.00 .. 70.00 Hz 61.00 Hz 81-4 Pickup
5414 81-4 DELAY 81 O/U Freq. 0.00 .. 100.00 sec; ∞ 30.00 sec 81-4 Time delay
5415A DO differential 81 O/U Freq. 0.02 .. 1.00 Hz 0.02 Hz Dropout differential
5421 FCT 81-1 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-1 Over/Under Frequency Protec-
tion
5422 FCT 81-2 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-2 Over/Under Frequency Protec-
tion
5423 FCT 81-3 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-3 Over/Under Frequency Protec-
tion
5424 FCT 81-4 O/U 81 O/U Freq. OFF
ON f>
ON f<
OFF 81-4 Over/Under Frequency Protec-
tion
5501 LR t Monitor Load Restore 1 .. 3600 sec 3600 sec Load restoration monitor time
5502 LR Max. Cycles Load Restore 1 .. 10 2 Load restoration maximal no. of
cycles
5520 LR1 Load Restore
Load Restore
ON
OFF
OFF Load restoration element 1
5521 LR1 Start Load Restore 40.00 .. 60.00 Hz 49.50 Hz Load restoration elem. 1 start fre-
quency
5522 LR1 Start Load Restore 50.00 .. 70.00 Hz 59.50 Hz Load restoration elem. 1 start fre-
quency
5523 LR1 Pickup Load Restore 0.02 .. 2.00 Hz 0.04 Hz Load restoration element 1 Pickup
5524 LR1 t pickup Load Restore 0 .. 10800 sec 600 sec Load restoration element 1 Pickup
time
5525 LR1 Dropout Load Restore 0.00 .. 2.00 Hz 0.02 Hz Load restoration element 1 Dropout
5526 LR1 t dropout Load Restore 0 .. 10800 sec 60 sec Load restoration element 1 Dropout
time
5527 LR1 t CB Close Load Restore 0.01 .. 32.00 sec; 0 1.00 sec Load restoration element 1 CB
Close time
5528 LR1 after 81-1 Load Restore YES
NO
NO Load restoration element 1 after 81-
1
Addr. Parameter Function Setting Options Default Setting Comments
