Siemens SIPROTEC 7RW80 User Manual

Appendix
A.7 Settings
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
229
5529 LR1 after 81-2 Load Restore YES
NO
NO Load restoration element 1 after 81-
2
5530 LR1 after 81-3 Load Restore YES
NO
NO Load restoration element 1 after 81-
3
5531 LR1 after 81-4 Load Restore YES
NO
NO Load restoration element 1 after 81-
4
5540 LR2 Load Restore
Load Restore
ON
OFF
OFF Load restoration element 2
5541 LR2 Start Load Restore 40.00 .. 60.00 Hz 49.00 Hz Load restoration elem. 2 start fre-
quency
5542 LR2 Start Load Restore 50.00 .. 70.00 Hz 59.00 Hz Load restoration elem. 2 start fre-
quency
5543 LR2 Pickup Load Restore 0.02 .. 2.00 Hz 0.04 Hz Load restoration element 2 Pickup
5544 LR2 t pickup Load Restore 0 .. 10800 sec 600 sec Load restoration element 2 Pickup
time
5545 LR2 Dropout Load Restore 0.00 .. 2.00 Hz 0.02 Hz Load restoration element 2 Dropout
5546 LR2 t dropout Load Restore 0 .. 10800 sec 60 sec Load restoration element 2 Dropout
time
5547 LR2 t CB Close Load Restore 0.01 .. 32.00 sec; 0 1.00 sec Load restoration element 2 CB
Close time
5548 LR2 after 81-1 Load Restore YES
NO
NO Load restoration element 2 after 81-
1
5549 LR2 after 81-2 Load Restore YES
NO
NO Load restoration element 2 after 81-
2
5550 LR2 after 81-3 Load Restore YES
NO
NO Load restoration element 2 after 81-
3
5551 LR2 after 81-4 Load Restore YES
NO
NO Load restoration element 2 after 81-
4
5560 LR3 Load Restore
Load Restore
ON
OFF
OFF Load restoration element 3
5561 LR3 Start Load Restore 40.00 .. 60.00 Hz 47.50 Hz Load restoration elem. 3 start fre-
quency
5562 LR3 Start Load Restore 50.00 .. 70.00 Hz 57.50 Hz Load restoration elem. 3 start fre-
quency
5563 LR3 Pickup Load Restore 0.02 .. 2.00 Hz 0.04 Hz Load restoration element 3 Pickup
5564 LR3 t pickup Load Restore 0 .. 10800 sec 600 sec Load restoration element 3 Pickup
time
5565 LR3 Dropout Load Restore 0.00 .. 2.00 Hz 0.02 Hz Load restoration element 3 Dropout
5566 LR3 t dropout Load Restore 0 .. 10800 sec 60 sec Load restoration element 3 Dropout
time
5567 LR3 t CB Close Load Restore 0.01 .. 32.00 sec; 0 1.00 sec Load restoration element 3 CB
Close time
5568 LR3 after 81-1 Load Restore YES
NO
NO Load restoration element 3 after 81-
1
5569 LR3 after 81-2 Load Restore YES
NO
NO Load restoration element 3 after 81-
2
5570 LR3 after 81-3 Load Restore YES
NO
NO Load restoration element 3 after 81-
3
5571 LR3 after 81-4 Load Restore YES
NO
NO Load restoration element 3 after 81-
4
5580 LR4 Load Restore
Load Restore
ON
OFF
OFF Load restoration element 4
5581 LR4 Start Load Restore 40.00 .. 60.00 Hz 47.50 Hz Load restoration elem. 4 start fre-
quency
5582 LR4 Start Load Restore 50.00 .. 70.00 Hz 57.50 Hz Load restoration elem. 4 start fre-
quency
5583 LR4 Pickup Load Restore 0.02 .. 2.00 Hz 0.04 Hz Load restoration element 4 Pickup
5584 LR4 t pickup Load Restore 0 .. 10800 sec 600 sec Load restoration element 4 Pickup
time
5585 LR4 Dropout Load Restore 0.00 .. 2.00 Hz 0.02 Hz Load restoration element 4 Dropout
5586 LR4 t dropout Load Restore 0 .. 10800 sec 60 sec Load restoration element 4 Dropout
time
5587 LR4 t CB Close Load Restore 0.01 .. 32.00 sec; 0 1.00 sec Load restoration element 4 CB
Close time
Addr. Parameter Function Setting Options Default Setting Comments
