Appendix
A.8 Information List
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
233
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO 135 51 1 Yes
8 >Setting Group Select Bit 1 (>Set
Group Bit1)
Change Group SP * * * LED BI BO 135 52 1 Yes
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP On
Off
**LEDBO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP On
Off
**LEDBO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP On
Off
**LEDBO
15 >Test mode (>Test mode) Device, General SP * * * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device, General SP * * * LED BI BO 135 54 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device, General OUT On
Off
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device, General IntSP On
Off
* * LED BO 160 18 1 Yes
55 Reset Device (Reset Device) Device, General OUT on * * 160 4 1 No
56 Initial Start of Device (Initial Start) Device, General OUT on * * LED BO 160 5 1 No
67 Resume (Resume) Device, General OUT on * * LED BO
68 Clock Synchronization Error
(Clock SyncError)
Device, General OUT On
Off
**LEDBO
69 Daylight Saving Time (DayLight-
SavTime)
Device, General OUT On
Off
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device, General OUT On
Off
* * LED BO 160 22 1 Yes
71 Settings Check (Settings Check) Device, General OUT * * * LED BO
72 Level-2 change (Level-2 change) Device, General OUT On
Off
**LEDBO
73 Local setting change (Local
change)
Device, General OUT * * *
110 Event lost (Event Lost) Device, General OUT_
Ev
on * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Device, General OUT on * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device, General OUT On
Off
* * LED BO 135 145 1 Yes
126 Protection ON/OFF (via system
port) (ProtON/OFF)
P.System Data 2 IntSP On
Off
**LEDBO
140 Error with a summary alarm
(Error Sum Alarm)
Device, General OUT On
Off
* * LED BO 160 47 1 Yes
160 Alarm Summary Event (Alarm
Sum Event)
Device, General OUT On
Off
* * LED BO 160 46 1 Yes
167 Failure: Voltage Balance (Fail V
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 186 1 Yes
170.0001 >25-group 1 activate (>25-1 act) SYNC function 1 SP On
Off
* LED BI
170.0043 >25 Synchronization request
(>25 Sync requ.)
SYNC function 1 SP On
Off
* LED BI
170.0049 25 Sync. Release of CLOSE
Command (25 CloseRelease)
SYNC function 1 OUT On
Off
* LED BO 41 201 1 Yes
170.0050 25 Synchronization Error (25
Sync. Error)
SYNC function 1 OUT On
Off
* LED BO 41 202 1 Yes
170.0051 25-group 1 is BLOCKED (25-1
BLOCK)
SYNC function 1 OUT On
Off
* LED BO 41 204 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
