Siemens SIPROTEC 7SJ62 User Manual

Functions
2.4 Dynamic Cold Load Pickup
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
127
1808 50c-3 PICKUP 1A 1.00 .. 35.00 A; ∞∞A 50c-3 Pickup
5A 5.00 .. 175.00 A; ∞∞A
1809 50c-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 50c-3 Time Delay
1901 50Nc-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 7.00 A 50Nc-2 Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
1902 50Nc-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 50Nc-2 Time Delay
1903 50Nc-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 1.50 A 50Nc-1 Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
1904 50Nc-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 50Nc-1 Time Delay
1905 51Nc PICKUP 1A 0.05 .. 4.00 A 1.00 A 51Nc Pickup
5A 0.25 .. 20.00 A 5.00 A
1906 51Nc T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 51Nc Time Dial
1907 51Nc T-DIAL 0.50 .. 15.00 ; ∞ 5.00 51Nc Time Dial
1908 50Nc-3 PICKUP 0.25 .. 35.00 A; ∞∞A 50Nc-3 Pickup
1909 50Nc-3 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 50Nc-3 Time Delay
2001 67c-2 PICKUP 1A 0.10 .. 35.00 A; ∞ 10.00 A 67c-2 Pickup
5A 0.50 .. 175.00 A; ∞ 50.00 A
2002 67c-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67c-2 Time Delay
2003 67c-1 PICKUP 1A 0.10 .. 35.00 A; ∞ 2.00 A 67c-1 Pickup
5A 0.50 .. 175.00 A; ∞ 10.00 A
2004 67c-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 67c-1 Time Delay
2005 67c-TOC PICKUP 1A 0.10 .. 4.00 A 1.50 A 67c Pickup
5A 0.50 .. 20.00 A 7.50 A
2006 67c-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 67c Time Dial
2007 67c-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67c Time Dial
2101 67Nc-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 7.00 A 67Nc-2 Pickup
5A 0.25 .. 175.00 A; ∞ 35.00 A
2102 67Nc-2 DELAY 0.00 .. 60.00 sec; ∞ 0.00 sec 67Nc-2 Time Delay
2103 67Nc-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 1.50 A 67Nc-1 Pickup
5A 0.25 .. 175.00 A; ∞ 7.50 A
2104 67Nc-1 DELAY 0.00 .. 60.00 sec; ∞ 0.30 sec 67Nc-1 Time Delay
2105 67Nc-TOC PICKUP 1A 0.05 .. 4.00 A 1.00 A 67Nc-TOC Pickup
5A 0.25 .. 20.00 A 5.00 A
2106 67Nc-TOC T-DIAL 0.05 .. 3.20 sec; ∞ 0.50 sec 67Nc-TOC Time Dial
2107 67Nc-TOC T-DIAL 0.50 .. 15.00 ; ∞ 5.00 67Nc-TOC Time Dial
Addr. Parameter C Setting Options Default Setting Comments
