Siemens SIPROTEC 7SJ62 User Manual

Functions
2.14 Automatic Reclosing System 79
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
267
Note Regarding Settings List for Automatic Reclosing Function
The setting options of address 7137 Cmd.via control are generated dynamically according to the current
configuration.
2.14.7 Settings
Addr. Parameter Setting Options Default Setting Comments
7101 FCT 79 OFF
ON
OFF 79 Auto-Reclose Function
7103 BLOCK MC Dur. 0.50 .. 320.00 sec; 0 1.00 sec AR blocking duration after manual
close
7105 TIME RESTRAINT 0.50 .. 320.00 sec 3.00 sec 79 Auto Reclosing reset time
7108 SAFETY 79 ready 0.01 .. 320.00 sec 0.50 sec Safety Time until 79 is ready
7113 CHECK CB? No check
Chk each cycle
No check Check circuit breaker before AR?
7114 T-Start MONITOR 0.01 .. 320.00 sec; ∞ 0.50 sec AR start-signal monitoring time
7115 CB TIME OUT 0.10 .. 320.00 sec 3.00 sec Circuit Breaker (CB) Supervision
Time
7116 Max. DEAD EXT. 0.50 .. 1800.00 sec; ∞ 100.00 sec Maximum dead time extension
7117 T-ACTION 0.01 .. 320.00 sec; ∞∞sec Action time
7118 T DEAD DELAY 0.0 .. 1800.0 sec; ∞ 1.0 sec Maximum Time Delay of Dead-
Time Start
7127 DEADTIME 1: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Phase Fault
7128 DEADTIME 1: G 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Ground Fault
7129 DEADTIME 2: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Phase Fault
7130 DEADTIME 2: G 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Ground Fault
7131 DEADTIME 3: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Phase Fault
7132 DEADTIME 3: G 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Ground Fault
7133 DEADTIME 4: PH 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Phase Fault
7134 DEADTIME 4: G 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Ground Fault
7135 # OF RECL. GND 0 .. 9 1 Number of Reclosing Cycles
Ground
7136 # OF RECL. PH 0 .. 9 1 Number of Reclosing Cycles
Phase
7137 Cmd.via control (Setting options depend
on configuration)
None Close command via control
device
7138 Internal SYNC (Setting options depend
on configuration)
None Internal 25 synchronisation
7139 External SYNC YES
NO
NO External 25 synchronisation
7140 ZONE SEQ.COORD. OFF
ON
OFF ZSC - Zone sequence coordina-
tion
