Appendix
A.9 Information List
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
653
A.9 Information List
Indications for IEC 60 870-5-103 are always reported ON / OFF if they are subject to general interrogation for
IEC 60 870-5-103. If not, they are reported only as ON.
New user-defined indications or such newly allocated to IEC 60 870-5-103 are set to ON / OFF and subjected
to general interrogation if the information type is not a spontaneous event („.._Ev“). Further information with
regard to the indications is set out in the SIPROTEC 4 System Description, Order No. E50417-H1100-C151.
In columns „Event Log“, „Trip Log“ and „Ground Fault Log“ the following applies:
UPPER CASE NOTATION “ON/OFF”: definitely set, not allocatable
lower case notation “on/off”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
In column „Marked in Oscill.Record“ the following applies:
UPPER CASE NOTATION “M”: definitely set, not allocatable
lower case notation “m”: preset, allocatable
*: not preset, allocatable
<blank>: neither preset nor allocatable
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
- >Back Light on (>Light on) Device, General SP On
Off
**LEDBIBO
- Reset LED (Reset LED) Device, General IntSP on * * LED BO 160 19 1 No
- Stop data transmission (DataS-
top)
Device, General IntSP On
Off
* * LED BO 160 20 1 Yes
- Test mode (Test mode) Device, General IntSP On
Off
* * LED BO 160 21 1 Yes
- Feeder GROUNDED (Feeder
gnd)
Device, General IntSP * * * LED BO
- Breaker OPENED (Brk
OPENED)
Device, General IntSP * * * LED BO
- Hardware Test Mode (HWTest-
Mod)
Device, General IntSP On
Off
**LEDBO
- Clock Synchronization (Synch-
Clock)
Device, General IntSP
_Ev
** *
- Error FMS FO 1 (Error FMS1) Device, General OUT On
Off
* LED BO
- Error FMS FO 2 (Error FMS2) Device, General OUT On
Off
* LED BO
- Disturbance CFC (Distur.CFC) Device, General OUT On
Off
* LED BO
- Fault Recording Start (FltRecSta) Osc. Fault Rec. IntSP On
Off
*mLEDBO
- Setting Group A is active
(GroupA act)
Change Group IntSP On
Off
* * LED BO 160 23 1 Yes
- Setting Group B is active
(GroupB act)
Change Group IntSP On
Off
* * LED BO 160 24 1 Yes
