A.5 Default Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
616
A.5.2 Binary Input
Table A-4 Binary input presettings for all devices and ordering variants
Table A-5 Further binary input presettings for 7SJ641/2/5/7
A.5.3 Binary Output
Table A-6 Further Output Relay Presettings for all 7SJ62
Table A-7 Further Output Relay Presettings for 7SJ62
Binary Input Default function Function No. Description
BI1 >BLOCK 50-2 1721 >BLOCK 50-2
>BLOCK 50N-2 1724 >BLOCK 50N-2
BI2 >Reset LED 5 >Reset LED
BI3 >Light on >Back Light on
BI4 >52-b 4602 >52-b contact (OPEN, if bkr is
closed)
52Breaker 52 Breaker
BI5 >52-a 4601 >52-a contact (OPEN, if bkr is open)
52Breaker 52 Breaker
Binary Input Default function Function No. Description
BI6 Disc.Swit. Disconnect Switch
BI7 Disc.Swit. Disconnect Switch
BI8 GndSwit. Ground Switch
BI9 GndSwit. Ground Switch
BI11 >CB ready >CB ready Spring is charged
BI12 >DoorClose >Door closed
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO3 52Breaker 52 Breaker
79 Close 2851 79 - Close command
Binary Output Default function Function No. Description
BO4 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail V balance 167 Failure: Voltage Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
Fail Ph. Seq. V 176 Failure: Phase Sequence Voltage
BO7 Relay PICKUP 501 Relay PICKUP
