Functions
2.1 General
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
62
2.1.7 EN100-Module
2.1.7.1 Functional Description
The EN100-Module enables integration of the 7SJ62/64 in 100-Mbit communication networks in control and
automation systems with the protocols according to IEC 61850 standard. This standard permits uniform com-
munication of the devices without gateways and protocol converters. Even when installed in heterogeneous
environments, SIPROTEC 4 relays therefore provide for open and interoperable operation. Parallel to the
process control integration of the device, this interface can also be used for communication with DIGSI and for
inter-relay communication via GOOSE.
2.1.7.2 Setting Notes
Interface Selection
No special settings are required for operating the Ethernet system interface module (IEC 1850, EN100-
Module). If the ordered version of the device is equipped with such a module, it is automatically allocated to
the interface available for it, namely Port B.
2.1.7.3 Information List
No. Information Type of In-
formation
Comments
009.0100 Failure Modul IntSP Failure EN100 Modul
009.0101 Fail Ch1 IntSP Failure EN100 Link Channel 1 (Ch1)
009.0102 Fail Ch2 IntSP Failure EN100 Link Channel 2 (Ch2)
