4.17 Intermittent Ground Fault Protection
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
517
4.17 Intermittent Ground Fault Protection
Setting Ranges / Increments
Times
Tolerances
Influencing Variables
Pickup Threshold
with IN
with 3I0
with INs
for I
Nom
= 1 A
for I
Nom
= 5 A
for I
Nom
= 1 A
for I
Nom
= 5 A
0.05 A to 35.00 A
0.25 A to 175.00 A
0.05 A to 35.00 A
0.25 A to 175.00 A
0.005 A to 1.500 A
Increments 0.01 A
Increments 0.01 A
Increments 0.01 A
Increments 0.01 A
Increments 0.001 A
Pickup extension time T
v
0.00 s to 10.00 s Increments 0.01 s
Ground Fault Accumulation Time T
sum
0.00 s to 100.00 s Increments 0.01 s
Reset Time for Accumulation T
res
1 s to 600 s Increments 1 s
Number of Pickups for Intermittent Ground
Fault
2 to 10 Increments 1
Pickup Times
– Current = 1.25 x Pickup Value
– for ≥ 2 · Pickup Value
Dropout Time (without extension time)
Approx. 30 ms
Approx. 22 ms
Approx. 22 ms
Pickup threshold I
Times T
V
, T
sum
, T
res
3 % of set value or 10 mA for I
Nom
= 1 A
or 50 mA for I
Nom
= 5 A
1 % of setting value or 10 ms
Power supply direct voltage in range 0.8 ≤ V
PS
/V
PSNom
≤ 1.15 <1 %
Temperature in range 23.00 °F (-5 °C) ≤ Θ
amb
≤ 131.00 °F (55 °C) <0.5 %/ K
Frequency in range 0.95 ≤ f/f
Nom
≤ 1.05 <5% relating to the set time
