Functions
2.1 General
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
60
2.1.6.3 Settings
The table indicates region-specific default settings. Column C (configuration) indicates the corresponding sec-
ondary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
1101 FullScaleVolt. 0.10 .. 800.00 kV 12.00 kV Measurem:FullScaleVolt-
age(Equipm.rating)
1102 FullScaleCurr. 10 .. 50000 A 100 A Measurem:FullScaleCur-
rent(Equipm.rating)
1103 RE/RL -0.33 .. 7.00 1.00 Zero seq. compensating
factor RE/RL
1104 XE/XL -0.33 .. 7.00 1.00 Zero seq. compensating
factor XE/XL
1105 x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi feeder reactance per mile:
x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
1106 x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km feeder reactance per km:
x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
1107 I MOTOR START 1A 0.40 .. 10.00 A 2.50 A Motor Start Current (Block
49, Start 48)
5A 2.00 .. 50.00 A 12.50 A
1108 P,Q sign not reversed
reversed
not reversed P,Q operational measured
values sign
1109 Line angle 10 .. 89 ° 85 ° Line angle
1110 Line length 0.1 .. 1000.0 km 100.0 km Line length in kilometer
1111 Line length 0.1 .. 650.0 Miles 62.1 Miles Line length in miles
6001 S1: RE/RL -0.33 .. 7.00 1.00 S1: Zero seq. compensat-
ing factor RE/RL
6002 S1: XE/XL -0.33 .. 7.00 1.00 S1: Zero seq. compensat-
ing factor XE/XL
6003 S1: x' 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S1: feeder reactance per
mile: x'
6004 S1: x' 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S1: feeder reactance per
km: x'
6005 S1: Line angle 10 .. 89 ° 85 ° S1: Line angle
6006 S1: line length 0.1 .. 650.0 Miles 62.1 Miles S1: Line length in miles
6007 S1: Line length 0.1 .. 1000.0 km 100.0 km S1: Line length in kilome-
ter
6011 S2: RE/RL -0.33 .. 7.00 1.00 S2: Zero seq. compensat-
ing factor RE/RL
6012 S2: XE/XL -0.33 .. 7.00 1.00 S2: Zero seq. compensat-
ing factor XE/XL
6013 S2: x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi S2: feeder reactance per
mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
6014 S2: x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km S2: feeder reactance per
km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
