Technical Data
4.1 General Device Data
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
478
4.1.9 Certifications
4.1.10 Design
UL Listing UL recognition
7SJ62**-*B***-****
Models with threaded ter-
minals
7SJ62**-*D***-****
Types with
plug-in terminals
7SJ62**-*E***-****
7SJ64**-*B***-**** 7SJ64**-*A***-****
7SJ64**-*C***-**** 7SJ64**-*D***-****
7SJ64**-*E***-**** 7SJ64**-*G***-****
7SJ64**-*F***-****
Case 7XP20
Dimensions see dimensional drawings, Section 4.27
Variant Case Size Weight (mass)
7SJ62**-*B in surface mounting housing
1
/
3
8.8 lb or 4.5 kg
7SJ62**-*D/E in flush mounting housing
1
/
3
8.8 lb or 4 kg
7SJ640*-*B in surface mounting housing
1
/
3
17.4 lb or 8 kg
7SJ641/2*-*B in surface mounting housing
1
/
2
24.25 lb or 11 kg
7SJ645*-*B in surface mounting housing
1
/
1
33.07 lb or 15 kg
7SJ641/2*-*A/C in housing for detached operator panel
1
/
2
17.4 lb or 8 kg
7SJ645*-*A/C in housing for detached operator panel
1
/
1
26.45 lb or 12 kg
7SJ647*-*A/C for mounting with detached operator panel
1
/
1
12.5 kg
7SJ641/2*-*F/G in housing without operator panel
1
/
2
17.4 lb or 8 kg
7SJ645*-*F/G in housing without operator panel
1
/
1
26.45 lb or 12 kg
7SJ647*-*F/G for housing without operator panel
1
/
1
12.5 kg
7SJ640*-*D/E in flush mounting housing
1
/
3
11.02 lb or 5 kg
7SJ641/2*-*D/E in flush mounting housing
1
/
2
13.23 lb or 6 kg
7SJ645*-*D/E in flush mounting housing
1
/
1
22.05 lb or 10 kg
7SJ647*-*D/E for panel surface mounting
1
/
1
10.5 kg
Detached operator panel 5.51 lb or 2.5 kg
International Protection Under IEC 60529
for equipment of the surface mounting housing IP 51
in flush mounted case and in model with detached op-
erator panel
Front IP 51
Rear IP 50
For personal protection IP 2x with cover cap
UL-certification conditions „For use on a Flat Surface of a Type 1 Enclosure“
