Functions
2.5 Single-Phase Overcurrent Protection
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
139
2.5.5 Settings
The table indicates region-specific default settings. Column C (configuration) indicates the corresponding sec-
ondary nominal current of the current transformer.
2.5.6 Information List
Addr. Parameter C Setting Options Default Setting Comments
2701 50 1Ph OFF
ON
OFF 50 1Ph
2702 50 1Ph-2 PICKUP 1A 0.05 .. 35.00 A; ∞ 0.50 A 50 1Ph-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
2703 50 1Ph-2 PICKUP 0.003 .. 1.500 A; ∞ 0.300 A 50 1Ph-2 Pickup
2704 50 1Ph-2 DELAY 0.00 .. 60.00 sec; ∞ 0.10 sec 50 1Ph-2 Time Delay
2705 50 1Ph-1 PICKUP 1A 0.05 .. 35.00 A; ∞ 0.20 A 50 1Ph-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
2706 50 1Ph-1 PICKUP 0.003 .. 1.500 A; ∞ 0.100 A 50 1Ph-1 Pickup
2707 50 1Ph-1 DELAY 0.00 .. 60.00 sec; ∞ 0.50 sec 50 1Ph-1 Time Delay
No. Information Type of In-
formation
Comments
5951 >BLK 50 1Ph SP >BLOCK 50 1Ph
5952 >BLK 50 1Ph-1 SP >BLOCK 50 1Ph-1
5953 >BLK 50 1Ph-2 SP >BLOCK 50 1Ph-2
5961 50 1Ph OFF OUT 50 1Ph is OFF
5962 50 1Ph BLOCKED OUT 50 1Ph is BLOCKED
5963 50 1Ph ACTIVE OUT 50 1Ph is ACTIVE
5966 50 1Ph-1 BLK OUT 50 1Ph-1 is BLOCKED
5967 50 1Ph-2 BLK OUT 50 1Ph-2 is BLOCKED
5971 50 1Ph Pickup OUT 50 1Ph picked up
5972 50 1Ph TRIP OUT 50 1Ph TRIP
5974 50 1Ph-1 PU OUT 50 1Ph-1 picked up
5975 50 1Ph-1 TRIP OUT 50 1Ph-1 TRIP
5977 50 1Ph-2 PU OUT 50 1Ph-2 picked up
5979 50 1Ph-2 TRIP OUT 50 1Ph-2 TRIP
5980 50 1Ph I: VI 50 1Ph: I at pick up
