Siemens SIPROTEC 7SJ62 User Manual

Functions
2.1 General
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
38
142 49 Disabled
No ambient temp
With amb. temp.
Disabled 49 Thermal Overload Protection
143 66 #of Starts Disabled
Enabled
Disabled 66 Startup Counter for Motors
144 LOAD JAM PROT. Disabled
Enabled
Disabled Load Jam Protection
150 27/59 Disabled
Enabled
Disabled 27, 59 Under/Overvoltage Protec-
tion
154 81 O/U Disabled
Enabled
Disabled 81 Over/Underfrequency Protec-
tion
161 25 Function 1 Disabled
ASYN/SYNCHRON
SYNCHROCHECK
Disabled 25 Function group 1
162 25 Function 2 Disabled
ASYN/SYNCHRON
SYNCHROCHECK
Disabled 25 Function group 2
163 25 Function 3 Disabled
ASYN/SYNCHRON
SYNCHROCHECK
Disabled 25 Function group 3
164 25 Function 4 Disabled
ASYN/SYNCHRON
SYNCHROCHECK
Disabled 25 Function group 4
170 50BF Disabled
Enabled
enabled w/ 3I0>
Disabled 50BF Breaker Failure Protection
171 79 Auto Recl. Disabled
Enabled
Disabled 79 Auto-Reclose Function
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
180 Fault Locator Disabled
Enabled
Enabled Fault Locator
181 L-sections FL 1 Section
2 Sections
3 Sections
1 Section Line sections for fault locator
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
190 RTD-BOX INPUT Disabled
Port C
Disabled External Temperature Input
Addr. Parameter Setting Options Default Setting Comments
