Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
412
Pickup Voltage of BI4 to BI11
Table 3-11 Jumper settings for pickup voltages of binary inputs BI4 to BI11 on the input/output board
A–I/O-2 as from 7SJ62.../FF
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115/230 VAC
Binary inputs Jumper 19 VDC threshold
1)
88 VDC threshold
2)
176 VDC threshold
BI4 X21 L M H
BI5 X22 L M H
BI6 X23 L M H
BI7 X24 L M H
BI8 X25 L M H
BI9 X26 L M H
BI10 X27 L M H
BI11 X28 L M H
