Technical Data
4.1 General Device Data
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
473
DNP3.0 / MODBUS
RS485
Connection for flush-mounted casing Rear panel, mounting location „B“, 9-pin D-
SUB miniature connector
Connection for surface-mounted
casing
at the housing mounted case on the case
bottom
Test Voltage 500 VAC
Transmission Speed up to 19,200 Bd
Maximum Distance of Transmission max. 0.62 miles (1 km)
DNP3.0 / MODBUS
Fiber Optical Link
FO connector type ST–Connector Receiver/Transmitter
Connection for flush-mounted casing Rear panel, mounting location „B“
Connection for surface-mounted
casing
not available
Transmission Speed up to 19,200 Bd
Optical Wavelength λ = 820 nm
Laser Class 1 according to
EN 60825-1/-2
using glass fiber 50/125 µm or using glass
fiber 62.5/125 µm
Permissible Optical Link Signal Atten-
uation
max. 8 dB, with glass fiber 62.5/125 µm
Maximum Distance of Transmission max. 0.93 miles (1.5 km)
Ethernet electrical
(EN 100) for IEC61850
and DIGSI
Connection for flush-mounted casing rear panel, mounting location „B“
2 x RJ45 socket contact
100BaseT acc. to IEEE802.3
Connection for surface-mounted
casing
in console housing at case bottom
Test voltage (reg. socket) 500 V; 50 Hz
Transmission speed 100 MBit/s
Bridgeable distance 65.62 feet (20 m)
Ethernet optical (EN100)
for IEC61850 and DIGSI
Connection for
Flush-mounted case
rear panel, mounting location "B", ST-con-
nector
100BaseT acc. to IEEE802.3
Connection for
Surface-mounted case
(not available)
Transmission Speed 100 MBit/s
Optical wavelength 1300 nm
bridgeable distance max. 0.93 miles (1.5 km)
