Technical Data
4.24 User-defined Functions (CFC)
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
528
General Limits
MUL Multiplication X X X X
MV_GET_STATUS Decode status of a
value
XXXX
MV_SET_STATUS Set status of a value X X X X
NAND NAND - Gate X X X X
NEG Negator X X X X
NOR NOR - Gate X X X X
OR OR - Gate X X X X
REAL_TO_DINT Adaptor X X X X
REAL_TO_INT Conversion X X X X
REAL_TO_UINT Conversion X X X X
RISE_DETECT Rise detector X X X X
RS_FF RS- Flipflop — X X X
RS_FF_MEMO RS- Flipflop with state
memory
— X X X
SQUARE_ROOT Root Extractor X X X X
SR_FF SR- Flipflop — X X X
SR_FF_MEMO SR- Flipflop with state
memory
—X XX
ST_AND AND gate with status X X X X
ST_NOT Inverter with status X X X X
ST_OR OR gate with status X X X X
SUB Substraction X X X X
TIMER Timer — X X —
TIMER_SHORT Simple timer — X X —
UINT_TO_REAL Conversion X X X X
UPPER_SETPOINT Upper Limit X — — —
X_OR XOR - Gate X X X X
ZERO_POINT Zero Supression X — — —
Function Module Explanation Task Level
MW_
BEARB
PLC1_
BEARB
PLC_
BEARB
SFS_
BEARB
Description Limit Comments
Maximum number of all CFC charts
considering all task levels
32 When the limit is exceeded, the device rejects the parameter
set displaying an error message, restores the last valid pa-
rameter set and uses it for restarting.
Maximum number of all CFC charts
considering one task level
16 When the limit is exceeded, an error message is output by
the device. Consequently, the device is put into monitoring
mode. The red ERROR-LED lights up.
Maximum number of all CFC inputs
considering all charts
400 When the limit is exceeded, an error message is output by
the device. Consequently, the device starts monitoring. The
red ERROR-LED lights up.
Maximum number of reset-resistant
flipflops
D_FF_MEMO
350 When the limit is exceeded, an error message is output by
the device. Consequently, the device starts monitoring. The
red ERROR-LED lights up.
