A.1 Ordering Information and Accessories
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
560
RS485 Adapter Cable
Name Order Number
Y-adapter cable for devices with RS485 interface and sub-D connector on 2x
RJ45 sub-miniature connector for a RS485 bus setup with patch cables. 2–core
twisted, shielded, length 0.3 m; 1x sub-D pin 9–pole on 2x RJ45 sub-miniature
connector 8–pole
7XV5103–2BA00
IEC 60870–5–103 redundant, RS485 adapter cable
Name Order Number
Y-adapter cable for devices with redundant IEC 608070-5-103 RS485 interface
and RJ45 connector on 2x RJ45 sub-miniature connector for a RS485 bus setup
with patch cables. 2–core twisted, shielded, length 0.3 m; 1x RJ45 pin 8–pole on
2x RJ45 sub-miniature connector 8–pole
7XV5103–2CA00
RS485 Bus connector for RJ45
Name Order Number
RS485 bus connector with internal resistance 220 Ω between pin 1 and pin 2; 1x
RJ45 pin connector 8–pole
7XV5103–5BA00
