Appendix
A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
631
267 T 52 OPENING P.System Data 1 1 .. 500 ms 65 ms Opening Time (52 Breaker)
276 TEMP. UNIT P.System Data 1 Celsius
Fahrenheit
Celsius Unit of temperature measure-
ment
280 Holmgr. for Σi P.System Data 1 NO
YES
NO Holmgreen-conn. (for fast sum-i-
monit.)
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting
Group
401 WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
402 WAVEFORM DATA Osc. Fault Rec. Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
403 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device, General Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
611 Spont. FltDisp. Device, General YES
NO
NO Spontaneous display of flt.an-
nunciations
613A 50N/51N/67N w. P.System Data 1 Ignd (measured)
3I0 (calcul.)
Ignd (measured) 50N/51N/67N Ground Overcur-
rent with
614A OP. QUANTITY 59 P.System Data 1 Vphph
Vph-n
V1
V2
Vphph Opera. Quantity for 59 Overvolt.
Prot.
615A OP. QUANTITY 27 P.System Data 1 V1
Vphph
Vph-n
V1 Opera. Quantity for 27 Undervolt.
Prot.
640 Start image DD Device, General image 1
image 2
image 3
image 4
image 5
image 6
image 7
image 8
image 9
image 10
image 1 Start image Default Display
1101 FullScaleVolt. P.System Data 2 0.10 .. 800.00 kV 12.00 kV Measurem:FullScaleVolt-
age(Equipm.rating)
1102 FullScaleCurr. P.System Data 2 10 .. 50000 A 100 A Measurem:FullScaleCur-
rent(Equipm.rating)
1103 RE/RL P.System Data 2 -0.33 .. 7.00 1.00 Zero seq. compensating factor
RE/RL
1104 XE/XL P.System Data 2 -0.33 .. 7.00 1.00 Zero seq. compensating factor
XE/XL
1105 x' P.System Data 2 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi feeder reactance per mile: x'
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
1106 x' P.System Data 2 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km feeder reactance per km: x'
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
1107 I MOTOR START P.System Data 2 1A 0.40 .. 10.00 A 2.50 A Motor Start Current (Block 49,
Start 48)
5A 2.00 .. 50.00 A 12.50 A
1108 P,Q sign P.System Data 2 not reversed
reversed
not reversed P,Q operational measured
values sign
1109 Line angle P.System Data 2 10 .. 89 ° 85 ° Line angle
1110 Line length P.System Data 2 0.1 .. 1000.0 km 100.0 km Line length in kilometer
1111 Line length P.System Data 2 0.1 .. 650.0 Miles 62.1 Miles Line length in miles
1201 FCT 50/51 50/51 Overcur. ON
OFF
ON 50, 51 Phase Time Overcurrent
Addr. Parameter Function C Setting Options Default Setting Comments
