Appendix
A.8 Settings
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
636
2107 67Nc-TOC T-DIAL ColdLoadPickup 0.50 .. 15.00 ; ∞ 5.00 67Nc-TOC Time Dial
2201 INRUSH REST. 50/51 Overcur. OFF
ON
OFF Inrush Restraint
2202 2nd HARMONIC 50/51 Overcur. 10 .. 45 % 15 % 2nd. harmonic in % of fundamen-
tal
2203 CROSS BLOCK 50/51 Overcur. NO
YES
NO Cross Block
2204 CROSS BLK TIMER 50/51 Overcur. 0.00 .. 180.00 sec 0.00 sec Cross Block Time
2205 I Max 50/51 Overcur. 1A 0.30 .. 25.00 A 7.50 A Maximum Current for Inrush Re-
straint
5A 1.50 .. 125.00 A 37.50 A
2701 50 1Ph 50 1Ph OFF
ON
OFF 50 1Ph
2702 50 1Ph-2 PICKUP 50 1Ph 1A 0.05 .. 35.00 A; ∞ 0.50 A 50 1Ph-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
2703 50 1Ph-2 PICKUP 50 1Ph 0.003 .. 1.500 A; ∞ 0.300 A 50 1Ph-2 Pickup
2704 50 1Ph-2 DELAY 50 1Ph 0.00 .. 60.00 sec; ∞ 0.10 sec 50 1Ph-2 Time Delay
2705 50 1Ph-1 PICKUP 50 1Ph 1A 0.05 .. 35.00 A; ∞ 0.20 A 50 1Ph-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
2706 50 1Ph-1 PICKUP 50 1Ph 0.003 .. 1.500 A; ∞ 0.100 A 50 1Ph-1 Pickup
2707 50 1Ph-1 DELAY 50 1Ph 0.00 .. 60.00 sec; ∞ 0.50 sec 50 1Ph-1 Time Delay
3101 Sens. Gnd Fault Sens. Gnd Fault OFF
ON
ON with GF log
Alarm Only
OFF (Sensitive) Ground Fault
3102 CT Err. I1 Sens. Gnd Fault 0.001 .. 1.600 A 0.050 A Current I1 for CT Angle Error
3102 CT Err. I1 Sens. Gnd Fault 1A 0.05 .. 35.00 A 1.00 A Current I1 for CT Angle Error
5A 0.25 .. 175.00 A 5.00 A
3103 CT Err. F1 Sens. Gnd Fault 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I1
3104 CT Err. I2 Sens. Gnd Fault 0.001 .. 1.600 A 1.000 A Current I2 for CT Angle Error
3104 CT Err. I2 Sens. Gnd Fault 1A 0.05 .. 35.00 A 10.00 A Current I2 for CT Angle Error
5A 0.25 .. 175.00 A 50.00 A
3105 CT Err. F2 Sens. Gnd Fault 0.0 .. 5.0 ° 0.0 ° CT Angle Error at I2
3106 VPH MIN Sens. Gnd Fault 10 .. 100 V 40 V L-Gnd Voltage of Faulted Phase
Vph Min
3107 VPH MAX Sens. Gnd Fault 10 .. 100 V 75 V L-Gnd Voltage of Unfaulted
Phase Vph Max
3108 64-1 VGND Sens. Gnd Fault 1.8 .. 200.0 V; ∞ 40.0 V 64-1 Ground Displacement
Voltage
3109 64-1 VGND Sens. Gnd Fault 1.8 .. 170.0 V; ∞ 40.0 V 64-1 Ground Displacement
Voltage
3110 64-1 VGND Sens. Gnd Fault 10.0 .. 225.0 V; ∞ 70.0 V 64-1 Ground Displacement
Voltage
3111 T-DELAY Pickup Sens. Gnd Fault 0.04 .. 320.00 sec; ∞ 1.00 sec Time-DELAY Pickup
3112 64-1 DELAY Sens. Gnd Fault 0.10 .. 40000.00 sec; ∞ 10.00 sec 64-1 Time Delay
3113 50Ns-2 PICKUP Sens. Gnd Fault 0.001 .. 1.500 A 0.300 A 50Ns-2 Pickup
3113 50Ns-2 PICKUP Sens. Gnd Fault 1A 0.05 .. 35.00 A 10.00 A 50Ns-2 Pickup
5A 0.25 .. 175.00 A 50.00 A
3114 50Ns-2 DELAY Sens. Gnd Fault 0.00 .. 320.00 sec; ∞ 1.00 sec 50Ns-2 Time Delay
3115 67Ns-2 DIRECT Sens. Gnd Fault Forward
Reverse
Non-Directional
Forward 67Ns-2 Direction
3117 50Ns-1 PICKUP Sens. Gnd Fault 0.001 .. 1.500 A 0.100 A 50Ns-1 Pickup
3117 50Ns-1 PICKUP Sens. Gnd Fault 1A 0.05 .. 35.00 A 2.00 A 50Ns-1 Pickup
5A 0.25 .. 175.00 A 10.00 A
3118 50Ns-1 DELAY Sens. Gnd Fault 0.00 .. 320.00 sec; ∞ 2.00 sec 50Ns-1 Time delay
3119 51Ns PICKUP Sens. Gnd Fault 0.001 .. 1.400 A 0.100 A 51Ns Pickup
3119 51Ns PICKUP Sens. Gnd Fault 0.003 .. 0.500 A 0.004 A 51Ns Pickup
3119 51Ns PICKUP Sens. Gnd Fault 1A 0.05 .. 4.00 A 1.00 A 51Ns Pickup
5A 0.25 .. 20.00 A 5.00 A
Addr. Parameter Function C Setting Options Default Setting Comments
