Appendix
A.9 Information List
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
657
170.0043 >25 Syncronization request (>25
Sync req.)
SYNC function 4 SP On
Off
* LED BI
170.0049 25 Sync. Release of CLOSE
Command (25 CloseRelease)
SYNC function 1 OUT On
Off
* LED BO 41 201 1 Yes
170.0049 25 Sync. Release of CLOSE
Command (25 CloseRelease)
SYNC function 2 OUT On
Off
* LED BO
170.0049 25 Sync. Release of CLOSE
Command (25 CloseRelease)
SYNC function 3 OUT On
Off
* LED BO
170.0049 25 Sync. Release of CLOSE
Command (25 CloseRelease)
SYNC function 4 OUT On
Off
* LED BO
170.0050 25 Synchronization Error (25
Sync. Error)
SYNC function 1 OUT On
Off
* LED BO 41 202 1 Yes
170.0050 25 Synchronization Error (25
Sync. Error)
SYNC function 2 OUT On
Off
* LED BO
170.0050 25 Synchronization Error (25
Sync. Error)
SYNC function 3 OUT On
Off
* LED BO
170.0050 25 Synchronization Error (25
Sync. Error)
SYNC function 4 OUT On
Off
* LED BO
170.0051 25-group 1 is BLOCKED (25-1
BLOCK)
SYNC function 1 OUT On
Off
* LED BO 41 204 1 Yes
170.0051 25-group 2 is BLOCKED (25-2
BLOCK)
SYNC function 2 OUT On
Off
* LED BO
170.0051 25-group 3 is BLOCKED (25-3
BLOCK)
SYNC function 3 OUT On
Off
* LED BO
170.0051 25-group 4 is BLOCKED (25-4
BLOCK)
SYNC function 4 OUT On
Off
* LED BO
170.2007 25 Sync. Measuring request of
Control (25 Measu. req.)
SYNC function 1 SP On
Off
*LED
170.2007 25 Sync. Measuring request of
Control (25 Measu. req.)
SYNC function 2 SP On
Off
*LED
170.2007 25 Sync. Measuring request of
Control (25 Measu. req.)
SYNC function 3 SP On
Off
*LED
170.2007 25 Sync. Measuring request of
Control (25 Measu. req.)
SYNC function 4 SP On
Off
*LED
170.2008 >BLOCK 25-group 1 (>BLK 25-1) SYNC function 1 SP On
Off
* LED BI
170.2008 >BLOCK 25-group 2 (>BLK 25-2) SYNC function 2 SP On
Off
* LED BI
170.2008 >BLOCK 25-group 3 (>BLK 25-3) SYNC function 3 SP On
Off
* LED BI
170.2008 >BLOCK 25-group 4 (>BLK 25-4) SYNC function 4 SP On
Off
* LED BI
170.2009 >25 Direct Command output
(>25direct CO)
SYNC function 1 SP On
Off
* LED BI
17
0.2009 >25 Direct Command output
(>25direct CO)
SYNC function 2 SP On
Off
* LED BI
170.2009 >25 Direct Command output
(>25direct CO)
SYNC function 3 SP On
Off
* LED BI
170.2009 >25 Direct Command output
(>25direct CO)
SYNC function 4 SP On
Off
* LED BI
170.2011 >25 Start of synchronization (>25
Start)
SYNC function 1 SP On
Off
* LED BI
170.2011 >25 Start of synchronization (>25
Start)
SYNC function 2 SP On
Off
* LED BI
170.2011 >25 Start of synchronization (>25
Start)
SYNC function 3 SP On
Off
* LED BI
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
