Appendix
A.9 Information List
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
659
170.2025 25 Monitoring time exceeded (25
MonTimeExc)
SYNC function 4 OUT On
Off
* LED BO
170.2026 25 Synchronization conditions
okay (25 Synchron)
SYNC function 1 OUT On
Off
* LED BO 41 206 1 Yes
170.2026 25 Synchronization conditions
okay (25 Synchron)
SYNC function 2 OUT On
Off
* LED BO
170.2026 25 Synchronization conditions
okay (25 Synchron)
SYNC function 3 OUT On
Off
* LED BO
170.2026 25 Synchronization conditions
okay (25 Synchron)
SYNC function 4 OUT On
Off
* LED BO
170.2027 25 Condition V1>V2< fulfilled (25
V1> V2<)
SYNC function 1 OUT On
Off
* LED BO
170.2027 25 Condition V1>V2< fulfilled (25
V1> V2<)
SYNC function 2 OUT On
Off
* LED BO
170.2027 25 Condition V1>V2< fulfilled (25
V1> V2<)
SYNC function 3 OUT On
Off
* LED BO
170.2027 25 Condition V1>V2< fulfilled (25
V1> V2<)
SYNC function 4 OUT On
Off
* LED BO
170.2028 25 Condition V1<V2> fulfilled (25
V1< V2>)
SYNC function 1 OUT On
Off
* LED BO
170.2028 25 Condition V1<V2> fulfilled (25
V1< V2>)
SYNC function 2 OUT On
Off
* LED BO
170.2028 25 Condition V1<V2> fulfilled (25
V1< V2>)
SYNC function 3 OUT On
Off
* LED BO
170.2028 25 Condition V1<V2> fulfilled (25
V1< V2>)
SYNC function 4 OUT On
Off
* LED BO
170.2029 25 Condition V1<V2< fulfilled (25
V1< V2<)
SYNC function 1 OUT On
Off
* LED BO
170.2029 25 Condition V1<V2< fulfilled (25
V1< V2<)
SYNC function 2 OUT On
Off
* LED BO
170.2029 25 Condition V1<V2< fulfilled (25
V1< V2<)
SYNC function 3 OUT On
Off
* LED BO
170.2029 25 Condition V1<V2< fulfilled (25
V1< V2<)
SYNC function 4 OUT On
Off
* LED BO
170.2030 25 Voltage difference (Vdiff) okay
(25 Vdiff ok)
SYNC function 1 OUT On
Off
* LED BO 41 207 1 Yes
170.2030 25 Voltage difference (Vdiff) okay
(25 Vdiff ok)
SYNC function 2 OUT On
Off
* LED BO
170.2030 25 Voltage difference (Vdiff) okay
(25 Vdiff ok)
SYNC function 3 OUT On
Off
* LED BO
170.2030 25 Voltage difference (Vdiff) okay
(25 Vdiff ok)
SYNC fun
ction 4 OUT On
Off
* LED BO
170.2031 25 Frequency difference (fdiff)
okay (25 fdiff ok)
SYNC function 1 OUT On
Off
* LED BO 41 208 1 Yes
170.2031 25 Frequency difference (fdiff)
okay (25 fdiff ok)
SYNC function 2 OUT On
Off
* LED BO
170.2031 25 Frequency difference (fdiff)
okay (25 fdiff ok)
SYNC function 3 OUT On
Off
* LED BO
170.2031 25 Frequency difference (fdiff)
okay (25 fdiff ok)
SYNC function 4 OUT On
Off
* LED BO
170.2032 25 Angle difference (alphadiff)
okay (25 αdiff ok)
SYNC function 1 OUT On
Off
* LED BO 41 209 1 Yes
170.2032 25 Angle difference (alphadiff)
okay (25 αdiff ok)
SYNC function 2 OUT On
Off
* LED BO
170.2032 25 Angle difference (alphadiff)
okay (25 αdiff ok)
SYNC function 3 OUT On
Off
* LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
