3RT1/3RH1 contactors
SIRIUS System Manual
3-28
GWA 4NEB 430 0999-02b
Installation
The following types of installation are permissible for contactors and auxil-
iary contactors in ambient temperatures of up to 70 °C:
Frame size S00: installation in series
Frame sizes S0 to S3: The resistor block must be installed on the right next
to the contactor because of the connecting leads there.
Dimensions
When the resistor is mounted, the contactors of frame sizes S0 to S3
become wider (see Section 3.6, Dimensioned drawings).
Circuit diagrams
Frame size S00
Terminal markings in acc. with Terminal markings in acc. with
DIN EN 50 012 DIN EN 50 005
Contactors 3RT1017-2K.42-0LA0 Auxiliary contactors
3RH1122-2K.40-0LA0
Figure 3-10: Contactors with an extended operating range, circuit diagrams
Frame sizes S0 to S3
Terminal markings in acc. with EN 50 012
Contactors 3RT102.-, 3RT103.-, 3RT104.-3K.44-0LA0
With front-mounted 4-pole auxiliary switch block 3RH1921-1HA22
Figure 3-11: Contactors with an extended operating range, terminal markings
NC contact 21/22 is required for the wiring of the series resistor.
Circuit diagram for wiring of the series resistor
Figure 3-12: Contactors with an extended operating range, circuit diagram
Series resistor R
V
attached
NC contact wired
2 NO + 1 NC contacts available
L+
L-
S1
R
V
NSB00559a
135
642
A2-
K1
K1
E1+
L+
L-
S1
R
V
NSB00560a
A2-
K1
K1
E1+
13
14
23
24
31
32
2 NO + 2 NC contacts
Identification number 22
13513
14
6
42A2( )
A1 21
22
31
32
43
44
NSB00561 a
U
(+)
A1
A1
22
(-)
A2
NSB00562a
R
V
21
(-)(+)
A2
