3RV1 circuit breaker
SIRIUS System Manual
2-54
GWA 4NEB 430 0999-02b
Motorized remote-control mechanism
Figure 2-51: 3RV19. 6-3AP0 for circuit breaker
a) 3RV19 36-3AP0, frame size S2, 211 mm
b) 3RV19 46-3AP0, frame size S3, 236 mm
NSB00044
RESET I>
AUTOMATIC
REVISION
MANUAL
I
SI EMENS
∅
5
87
182
224
148
112
a)
