SIRIUS System Manual

GWA 4NEB 430 0999-02b

7-1

3RP10, 3RP15 solid-state time relays

Section Subject Page

7.1 Specifications/regulations/approvals 7-2

7.2 Device description 7-3

7.2.1 Device types 7-3

7.2.2 Installation 7-4

7.2.3 Special features 7-5

7.2.4 Notes on configuration 7-5

7.2.5 Explanation of terms 7-7

7.3 Applications and uses (types of function) 7-8

7.3.1 Multifunction (3RP10 00 solid-state time relay) 7-8

7.3.2 Multifunction (3RP15 05 solid-state time relay) 7-11

7.3.3 On-delay 7-16

7.3.4 Off-delay 7-17

7.3.5 Clock pulse generator (3RP15 55 solid-state time relay) 7-18

7.3.6 Star-delta function (3RP15 74/76 solid-state time relay) 7-19

7.3.7 Star-delta function with overtravel (3RP15 60 solid-state

time relay)

7-19

7.4 Accessories 7-20

7.4.1 Accessories for 3RP10 7-20

7.4.2 Accessories for 3RP15 05 7-20

7.5 Mounting and connection 7-22

7.5.1 Mounting 7-22

7.5.2 Connection 7-23

7.5.3 Circuit diagrams 7-24

7.6 Dimensioned drawings 7-25

7.7 Technical specifications 7-26
