Appendix
A.9 Dataset Object
SIRIUS 3RW5 EtherNet/IP communication module
90 Manual, 05/2019, A5E45131885002A/RS-AA/001
A.9.2 Measured values
Only read access (get, r) to the measured values is possible.
The instance of all measured values is 94 (0x5E).
Byte Attribute ID Data
format
Measured value Range of values Increment 3RW
52
1)
55
2)
16 501 UINT Remaining motor cooling time 0 … 1 800 s 0.1 s r r
18 502 UINT Motor temperature rise 0 … 1000 % 1 % r r
20 503 USINT Asymmetry 0 … 100 % 1 % - r
21 504 USINT Phase current I L1 (%) 0 … 796.9 % 3.125 % r r
22 505 USINT Phase current I L2 (%) 0 … 796.9 % 3.125 % r r
23 506 USINT Phase current I L3 (%) 0 … 796.9 % 3.125 % r r
25 508 USINT Output frequency 0 … 100 Hz 0.5 Hz - r
26 509 USINT Line frequency 0 … 100 Hz 0.5 Hz - r
27 510 UINT Line-to-line voltage U L1-L2 (rms) 0 … 1 500 V 0.1 V - r
29 511 UINT Line-to-line voltage U L2-L3 (rms) 0 … 1 500 V 0.1 V - r
31 512 UINT Line-to-line voltage U L3-L1 (rms) 0 … 1 500 V 0.1 V - r
33 513 DINT Phase current I L1 (rms) -20 000 …
20 000 A
0.01 A r r
37 514 DINT Phase current I L2 (rms) -20 000 …
20 000 A
0.01 A r r
41 515 DINT Phase current I L3 (rms) -20 000 …
20 000 A
0.01 A r r
48 518 USINT Switching element heating 0 … 250 % 1 % r r
49 519 UINT Remaining switching element cooling time 0 … 1 800 s 0.1 s r r
51 520 UINT Remaining time for motor overload
protection
0 … 6 500 s 0.1 s - r
53 521 DINT Active power -2 147.483 …
2 147.483 kW
0.0001 kW - r
59 523 USINT Power factor L1..3 0 … 1 0.01 - r
65 526 UINT Remaining switching frequency monitoring
time
0 … 65 535 s 1 s - r
67 528 USINT Phase current average (%) 0 … 796.9 % 3.125 % r r
69 530 DINT Phase current average (rms) -20 000 …
20 000 A
0.01 A r r
73 531 DINT Maximum phase current (rms) -20 000 …
20 000 A
0.01 A - r
77 ... 82 - - Reserved - - - -
1)
Supported by SIRIUS 3RW52 soft starter
2)
Supported by SIRIUS 3RW55 soft starter
