Siemens SIRIUS 3RW5 User Manual

Appendix
A.9 Dataset Object
SIRIUS 3RW5 EtherNet/IP communication module
Manual, 05/2019, A5E45131885002A/RS-AA/001
91
A.9.3 Statistic data
Only read access (get, r) to the statistic data is possible.
The instance of all statistic data is 95 (0x5F).
Byte Attribute ID Data
format
Statistic data Range of values Increment 3RW
52
1)
55
2)
83 601 UDINT Operating hours - device 0 … 4 294 967 295 s 1 s r r
87 602 UDINT Operating hours - motor 0 … 4 294 967 295 s 1 s r r
91 603 UDINT Number of starts motor CW 0 … 4 294 967 295 1 r r
95 604 UDINT Number of starts motor CCW 0 … 4 294 967 295 1 - r
99 605 UINT Number of motor overload trips 0 … 65 535 1 r r
101 606 UINT Last tripping current IA (%) 0 … 1 000 % 3.125 % r r
103 607 USINT Maximum phase current (%) 0 … 796.9 % 3.125 % r r
104 608 DINT Last tripping current IA (rms) -20 000 … 20 000 A 0.01 A r r
108 609 DINT Maximum phase current (rms) -20 000 … 20 000 A 0.01 A r r
112 611 UDINT Operating hours - motor current =
18 ... 49.9% x Iemax
0 … 4 294 967 295 s 1 s r r
116 612 UDINT Operating hours - motor current =
50 ... 89.9% x Iemax
0 … 4 294 967 295 s 1 s r r
120 613 UDINT Operating hours - motor current =
90 ... 119.9% x Iemax
0 … 4 294 967 295 s 1 s r r
124 614 UDINT Operating hours - motor current =
120 ... 1000% x Iemax
0 … 4 294 967 295 s 1 s r r
130 616 UINT Number of switching element overload
trips
0 … 65 535 1 r r
132 617 UINT Number of bypass overload trips 0 … 65 535 1 r r
140 620 UDINT Number of electrical braking stops 0 … 4 294 967 295 1 - r
144 621 UDINT Number of starts output 1 0 … 4 294 967 295 1 - r
148 622 UDINT Number of starts output 2 0 … 4 294 967 295 1 - r
152 623 UDINT Number of starts output 3 0 … 4 294 967 295 1 - r
156 624 UDINT Number of starts output 4 0 … 4 294 967 295 1 - r
194 632 REAL Active energy import (total) 0 … 4 294 967 295 Wh 1 Wh - r
198 633 REAL Active energy export (total) 0 … 4 294 967 295 Wh 1 Wh - r
202 634 UINT Last real starting time 0 … 1 000 s 0.1 s - r
1)
Supported by SIRIUS 3RW52 soft starter as from 3RW52 V2.0
2)
Supported by SIRIUS 3RW55 soft starter
