Requirements
Connection Establishment to SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 19/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
No. Instruction Note
5.
Select Type MPI.
6.
Set MPI address 0 for the
configuration computer.
7.
Select Subnet MPI(1) and set the
Transmission Rate to 12 MBaud
using the Properties button.
8.
Close all windows until
Properties – PG/PC is displayed.
9.
In the Assignment tab, select the
interface of the configuration
computer (e.g. CP5512 MPI) and
click the Assign button.
To Next Page
