SIVACON S8 Planning Principles – SIVACON S8 – System overview
2
3
4
5
6
7
8
9
10
11
1
These characteristics depend on the type of installation
among other things:
• Stand-alone
• At the wall (only for single-front design)
• Back to back (only for single-front design)
These determinations allow to specify cubicle design in
more detail (Fig. 2/1, Tab. 2/2 and Tab. 2/3). Further infor-
mation about the switchboard installation can be found in
Chapter 8 “Further planning notes”.
Cable/busbar entry
From the bottom From the top
Connection in cubicle
Front Rear
Side of connection
Operating panel
B
B
B
B
B
A
B
A
B
A
B
A
