SIVACON S8 Planning Principles – SIVACON S8 – System overview
Tab. 2/4: Cubicle dimensions
Fig. 2/2: Dimensions of enclosure parts
9 mm
25 mm
25 mm
45 mm
Door
Side panel
with
design strip
Side panel
without
design strip
Rear panel
Depth
Width
Cubicle height
Frame 2,000, 2,200 mm
Base Without, 100, 200 mm
Cubicle width
Dependent of:
- Cubicle type
- Rated device current
- Connecting position and/or cable/busbar entry
Cubicle depth
Type
Main busbar Cubicle depth
Location Rated current Front connection Rear connection
Entry from the
bottom
Entry from the top
Single front
Top
3,270 A 500, 800 mm 800 mm 800 mm
6,300 A
1)
800, 1,000 mm 1,200 mm 1,200 mm
Rear
4,000 A 600 mm 600 mm -
7,010 A 800 mm 800 mm -
Double front Rear
4,000 A 1,000 mm 1,000 mm -
7,010 A
1)
1,200 mm 1,200 mm -
1)
Frame height 2,200 mm
Tab. 2/5: Surface treatment
The cubicle dimensions listed in Tab. 2/4 do not factor in
the enclosure parts and no outer built-on parts.
For the dimensions of the cubicles' enclosure parts, please
refer to Fig. 2/2. For degrees of protection IPX1 and IPX3,
additional ventilation roof panels are mounted on the
cubicle.
The dimensions of the enclosure parts are within the
required minimum clearances for erecting the switchboard.
Doors can be fitted so that they close in escape direction.
The door stop can easily be changed later. The door hinges
allow for a door opening angle of up to 180° in case of
single installation of a cubicle and at least 125° when
cubicles are lined up. For more details, please refer to
Chapter 8 “Further planning notes”. The condition of sur-
faces of structural and enclosure parts is described in
Tab. 2/5.
Surface treatment
Frame components Sendzimir-galvanised
Enclosure Sendzimir-galvanised / powder-coated
Doors Powder-coated
Copper bars
Bare copper,
optionally silver-plated,
optionally tin-plated
Colour
Powder-coated
components
(layer thickness 100 ± 25 μm)
RAL7035, light grey (in accordance
with DIN 43656) or upon request
Design components Blue Green Basic
