SIVACON S8 Planning Principles – Universal mounting design
2
3
4
5
6
7
8
9
10
11
1
4.3.5 Ratings for cable feeders in SFD / HFD
Withdrawable units in SFD are applied up to a rated current
of 250 A. The two withdrawable unit variants SFD and HFD
can be mixed within one cubicle.
The thermal interaction of the feeders in the cubicle has to
be and is considered by specifying the rated diversity factor
(RDF):
Permissible continuous operational current (cable feeder) =
= rated current I
nc
x RDF
Small withdrawable unit
1)
Type
Nominal
device
current
Minimum withdrawable unit size (height)
Rated current I
nc
at 35 °C ambient temperature
3-pole 4-pole Non-ventilated Ventilated
Main switch and fuses
3)
3LD22 32 A
150 mm - ¼, ½ 150 mm - ¼, ½ 32 A 32 A
3LD25 63 A
200 mm - ¼, ½ 200 mm - ¼, ½ 52.5 A 55.5 A
Circuit-breakers
3RV2.1 16 A
150 mm - ¼, ½ - 14.6 A 15.2 A
3RV2.2 40 A
150 mm - ¼, ½ - 32 A 33.5 A
3RV2.3 52 A
150 mm - ½ - 40 A 41 A
3RV1.4 100 A
150 mm - ½ - 50 A 51.5 A
Normal withdrawable unit
Type
Nominal
device
current
Minimum withdrawable unit size (height)
Rated current I
nc
at 35 °C ambient temperature
3-pole 4-pole Non-ventilated Ventilated
Main switch and fuses
3)
3LD22 32 A
100 mm - 32 A 32 A
Switch-disconnectors with fuses
3)
3KL50 63 A
150 mm 150 mm 63 A 63 A
3KL52 125 A
150 mm 150 mm 117 A 122 A
3KL53 160 A
200 mm 200 mm 137 A 142 A
3KL55 250 A
300 mm 300 mm 220 A 222 A
3KL57 400 A
300 mm 300 mm 305 A 340 A
3KL61 630 A
400 mm 500 mm 430 A 485 A
Circuit-breakers
3RV2.1 16 A
100 mm - 14.6 A 15.2 A
3RV2.2 40 A
100 mm - 32 A 33.5 A
3RV2.3 52 A
150 mm - 40 A 41 A
3RV1.4 100 A
150 mm - 50 A 51.5 A
3VL1 160 A
200 mm 200 mm 135 A 141 A
3VL2 160 A
200 mm 200 mm 136 A 142 A
3VL3 250 A
200 mm 250 mm 201 A 217 A
3VL4 400 A
200 mm 400 mm 305 A 330 A
3VL5 630 A
300 mm 400 mm 375 A 415 A
3VL5 630 A
500 mm
2)
- 435 A 485 A
3VA10 100 A
150 mm 200 mm 92 A 97 A
3VA11 160 A
150 mm 200 mm 128 A 133 A
3VA12 250 A
200 mm 250 mm 218 A 226 A
3VA20 100 A
200 mm 200 mm 100 A 100 A
3VA21 160 A
200 mm 200 mm 155 A 160 A
3VA22 250 A
200 mm 250 mm 189 A 203 A
3VA23 400 A
300 mm 300 mm 320 A 350 A
3VA24 630 A
300 mm 400 mm 365 A 405 A
1)
Type: ¼ = small withdrawable unit size ¼
2)
Circuit-breaker in vertical mounting position
½ = small withdrawable unit size ½
3)
Rated current with fuse link = nominal device current
Tab. 4/17: Rated currents and minimum withdrawable unit heights for cable feeders in SFD / HFD
For the feeders in the cubicle, the rated diversity factor RDF
= 0.8 can be applied:
• regardless of the number of feeders in the cubicle
• regardless of the mounting position in the cubicle
Rated currents and minimum withdrawable unit heights for
cable feeders are stated in Tab. 4/17. For cubicles with a
very high packing and/or power density, a project-specific
assessment is recommended. Further information is availa-
ble from your Siemens contact.
