64
SIVACON S8 Planning Principles – Cubicles in fixed-mounted design
Vertical distribution busbar
The vertical distribution busbars with the phase conductors
L1, L2, L3 are arranged at the left in the cubicle. The PE, N
or PEN busbars are arranged in the cable connection com-
Tab. 6/14: Configuration data on cubicle design for customized solutions
Cubicle design
Cubicle width
Width of device
compartment
Cable connection
compartment
Vertical distribution
busbar
1,000 mm
1)
(600 mm +400 mm),
1,200 mm
1)
(600 mm + 600 mm)
600 mm Right Yes / No
200 mm
2)
, 350 mm
3)
, 400 mm, 600 mm,
800 mm, 850 mm
3)
, 1,000 mm
Corresponding to the cubicle
width
Without No
600 mm
4)
600 mm Rear Yes / No
1)
Front connection in the cubicle
2)
Width 200 mm as cubicle expansion
3)
Cubicle height 2,000 mm, single-front systems
4)
Rear connection in the cubicle
partment. In the case of 4-pole feeders, the N conductor is
allocated to the phase conductors L1, L2, L3 at the back of
the cubicle. Ratings are stated in Tab. 6/15.
Distribution busbar Profile bar Flat copper
1)
Cross section
400 mm
2
650 mm
2
1 x (40 mm x 10 mm) 2 x (40 mm x 10 mm)
Rated current at 35 °C ambient
temperature
Ventilated
905 A 1,100 A 865 A 1,120 A
Non-
ventilated
830 A 1,000 A 820 A 1,000 A
Rated short-time withstand
current I
cw
(1 sec)
2)
65 kA 65 kA 65 kA 65 kA
1)
Top main busbar position
2)
Rated conditional short-circuit current I
cc
= 150 kA
Tab. 6/15: Rating data of the vertical distribution busbar
Mounting plates
Cubicle height Main busbar Overall height of mounting plate Version
2,000 mm
No 1,600 mm
- Separated / unseparated
- Perforated / non-perforated
Yes 1,800 mm
2,200 mm
No 2,000 mm
Yes 1,800 mm
ALPHA 8GK rapid mounting kits
Cubicle height Main busbar
Compartment
Height Width
2,000 mm
Without 1,800 mm
350
1)
, 600, 800 mm
Rear position 1,650 mm
1)
No viewing door
Tab. 6/16: Configuration data on mounting options for customized solutions
Mounting options
The dimensions and arrangement options for mounting
plates and ALPHA 8GK rapid mounting kits are stated in
Tab. 6/16.
More detailed information on the ALPHA 8GK rapid mount-
ing kits is available in the relevant product catalogues.
