SDS1000X-E&SDS1000X-U User Manual
106
10. Press the Data Length softkey and set byte bits (5-8) by Universal Knob.
11. Press the Parity Check softkey to set the type of parity check (Even, Odd, Mark,
Space or None).
12. Press the Stop Bit softkey to set the length of stop bit (1, 1.5 or 2 bits).
13. Press the Next Page softkey.
14. Press the Bit Order softkey to select the bit order (LSB or MSB).
15. Press the Idle Level softkey to set the idle level (LOW or HIGH).
