SDS1000X-E&SDS1000X-U User Manual
111
CAN Trigger
This part will provide a brief introduction and description for the operation of the
CAN trigger.
Trigger Conditions
Start— the oscilloscope will be triggered at the start bit of a frame.
Remote — the oscilloscope will be triggered by a remote frame with specified
ID.
ID — the oscilloscope will be triggered by a remote or data frame that have
specified ID.
ID+DATA— the oscilloscope will be triggered by data frame that have specified
ID and data.
Error — the oscilloscope will be triggered by an error frame.
Operation Steps
1. Press the Setup to enter the TRIGGER function menu.
2. Press the Type and select Serial.
3. Press the Protocol and select CAN.
4. Press the Trigger Setting to enter the CAN TRIG SET menu.
5. Press the Condition and select the trigger condition by Universal Knob:
If you select the REMOTE and ID condition:
a. Press the ID Bits to set the length of ID (11bits or 29 bits).
b. Press the Curr ID Byte and use the Universal Knob to select the byte
that you want to set.
c. Press the ID and set the ID’s value by the Universal Knob.
(Tips: In order to make is convenient for the operator to set the parameters,
ID b is split into several bytes. For example, if the ID’s length is 11 bits, it
will be split into two bytes, a byte includes 8 bits. If “1st byte” is selected,
only the 8 least significant bits can be changed.)
If you select the ID+DATA condition:
a. Press the ID bits softkey to select the ID’s length (11 or 29 bits).
b. Press the Curr ID Byte softkey and use Universal Knob to select the byte
that you want to modify.
c. Press the ID softkey and set the ID’s value by Universal Knob.
d. Press the Data softkey and set the value of the first byte by Universal
