SIGLENT SDS1104X-E - Units for Math Waveforms

SDS1000X-E&SDS1000X-U User Manual
125
WWW.SIGLENT.COM
Units for Math Waveforms
Use the channel function menu to set the unit of each channel to “V” or “A”.
The oscilloscope math operation includes units as below:
Math Operation
Unit
Addition (+)or subtraction (-)
V, A
multiplication (*)
V
∧
2, A
∧
2 or W
division (/)
SDS1000X-E：None, Ω (Resistance unit Ohms) or
S (conductance unit Siemens)
SDS1000X-U：None, V*A^-1 or V^-1*A
FFT
dBVrms, Vrms, dBm, dBArms, Arms
differential (d/dt)
SDS1000X-E：V/S or A/S (V/second or A/second)
SDS1000X-U：V*S^-1 or A*S^-1
integral (∫dt)
VS or AS (V*second or A*second)
square root ( )
V
∧
1/2 or A
∧
1/2
