SSA3000X User Manual 31
Set the sweep mode to “Single”. The number on the parameter icon denotes the current sweep
number.
2. Numbers
Set the number of sweeps for a single sweep. In single sweep mode, the system executes the
specified number of sweeps and the number shown on the icon in the status bar at the left of the
screen varies with the process of the sweep.
3. Continue
Set the sweep mode to “Continue”. The character Cont on the parameter icon denotes the
analyzer is sweeping continuously.
 If the instrument is in single sweep mode and no measurement function is enabled, press this
key and the system will enter continuous sweep mode and sweep continuously if the trigger
conditions are satisfied.
 If the instrument is in single sweep mode and a measurement function is on, press this key
and the system will enter continuous sweep mode and measure continuously if the trigger
conditions are satisfied.
 In continuous sweep mode, the system will send a trigger initialization signal automatically
and enter the trigger condition judgment directly after each sweep.
Table 2-16 Sweep Times
Parameter
Explanation
Default
1
Range
1 ~ 9999
Unit
N/A
Knob Step
1
Direction Key Step
1
2.2.4.4 Sweep Mode
Sweep mode includes auto, sweep and FFT.
1. Auto
When the sweep mode is auto, the analyzer selects the sweep mode automatically between
Sweep and FFT Mode in the shortest time.
2. Sweep
Work in point-by-point scanning. The Sweep mode is only available when RBW is in 30 Hz – 1
MHz
3. FFT
Work in FFT scanning. The FFT mode is only available when RBW is in 1 Hz - 30 kHz.
When TG is on, the sweep mode is forced to Sweep.

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
