2.6 Shortcut Key
2.6.1 Preset
Recall the preset setting and restore the analyzer to a specified status.
 Press System ->Pwr On/Preset ->Preset to select “Def”, “Last” or “User”.
 Press Preset to load the factory settings listed in the following table (except items marked
with “**”) or User-defined settings.
Table 2-40 Factory Settings
Parameter
Default
Frequency
Center Freq
1.6 GHz
Start Freq
0 Hz
Stop Freq
3.2 GHz
Freq Step
Auto
Span
Span
3.2 GHz
X Scale\
Linear
Amplitude
Ref Level
0 dBm
Attenuator
Auto, 20 dB
Preamp
Off
Units
dBm
Scale/Div
10 dB
Scale Type
Log
Ref Offset
0 dBm
Corrections
Off
BW
RBW
Auto, 1 MHz
VBW
Auto, 1 MHz
VBW/RBW
1
Avg Type
Log Pwr
Filter
Gauss
Sweep
Sweep Time
Auto
Sweep Rule
Speed
Sweep
Continue
Sweep Mode
Auto
Numbers
1
Trig

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
