SSA3000X User Manual 10
means the instrument is upgrading
16
Sweep time
Sweep time
17
Span/Stop Frequency
The frequency range of the current sweep
18
Sweep progress bar
Sweep progress bar
19
Pass/Fail status
Pass/Fail status
20
VBW
Video bandwidth
21
Spectrum trace
Spectrum trace
22
RBW
Resolution bandwidth
23
Center/Start frequency
The frequency range of the current sweep
24, 25,
26, 27
Trace status
Set the trace A\B\C\D parameter.
Trace type ----
C&W: Clear Write,
MaxH: Max Hold,
MinH: Min Hold,
View: View,
AVG: Average and times.
Detect type ----
P-PK: Positive peak,
N-PK: Negative peak,
Samp: Sample,
Norm: Normal,
AVG: Average.
Q-PK: Quasi peak
28
AM or FM
AM or FM identification
29
PA
Enable or disable Preamplifier
30
FFT
Sweep mode is FFT
31
Single or Continue
Sweep mode single or continue
32
Average type
Log power, Power, Voltage
33
Trigger type
Free, Video, External trigger
34, 35
Ref offset
34：Ref offset identification;
35：Ref offset value
36
Scale/Div
Scale value
37
Scale type
Logarithm or linearity
1.7 Firmware Operation
1.7.1 System Information Check
Users can get the system information by press System->“System Info”, including
 Product Model, Serial and Host ID
 Software Version and Hardware Version
 Option Information

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
