SSA3000X User Manual 34
selected the point type. The range from 1 to 100
Add point
Add a new point for editing.
X-axis
Edit the X-axis value (frequency or time) of the current point. If the X-axis unit is
frequency and the Ref Freq is enabled, edit the frequency difference between the
frequency of the current point and the center frequency.
Amplitude
Edit the amplitude of the current point or line. If the Ref AMPT is enabled, edit the
amplitude difference between the amplitude of the current point and the reference
level.
Del Point
Delete the point you are editing.
Del All
Delete all point.
Save/Recall
Save or load the limit file.
2.2.6.5 Test
Enable or disable the limit test function.
2.2.6.6 Setup
1. Fail to stop
Select whether the instrument will continue or stop operation when a failure occurs.
2. Buzzer
Turn on or off the buzzer. When the buzzer is on, it beeps when a failure occurs.
3. X Axis
Set the X-axis unit to frequency or time unit.
Note that all the points of the current limit line will be deleted when the X-axis unit changes.
2.2.7 TG（Tracking Generator）
Set the parameters related to the tracking generator.
2.2.7.1 TG
When the TG is enabled, a signal with the same frequency of the current sweep signal will be
output from the [TG SOURCE] connector at the front panel. The power of the signal could be set
through the menu.
2.2.7.2 TG Level
Set the output power of the signal of the tracking generator.

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
