SSA3000X User Manual 35
Table 2-21 TG Level
Parameter
Explanation
Default
0 dB
Range
-20 dBm ~ 0 dBm
Unit
dBm
Knob Step
1 dB
Direction Key Step
10 dB
2.2.7.3 TG Level Offset
Assign a certain offset to the output power of the TG when gains or losses occur between the TG
output and external device in order to display the actual power value.
 This parameter only changes the readout of the TG output power, rather than the actual
value.
 The offset could be either a positive (gain in the external output) or a negative (loss in the
external output).
Table 2-22 TG Level Offset
Parameter
Explanation
Default
0 dB
Range
-200 dB ~ 200 dB
Unit
dB
Knob Step
1 dB
Direction Key Step
10 dB
2.2.7.4 Normalize
Normalization can eliminate the error of TG Level. Before using this function, connect the [TG
SOURCE] output terminal of the TG with the [RF INPUT] input terminal of the analyzer.
When enabled, the reference trace will be stored automatically after the current sweep finishes if
no reference trace is stored before. During the reference trace storage, the corresponding prompt
message is displayed.
When normalization is enabled, the corresponding value of the reference trace will be subtracted
from the trace data after every sweep.

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
