SIGLENT SSA3021X User Manual

SIGLENT
SSA3000X User Manual 0
Chapter 1 Quick Start
This chapter guides users to quickly get familiar with the appearance, dimensions, front/ rear panel
and the user interface, as well as announcements during first use of SSA3000X series spectrum
analyzer.
Subjects in this chapter:
 General Inspection
 Appearance and Dimension
 Preparing for Use
 The Front Panel
 Rear Panel
 Display Annotations
 Firmware Operation
 Menu Operation
 Parameter Setting
 Using Built-in Help
 Using the Security Lock

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
