SSA3000X User Manual 58
2. Load Option
Load license, enter license here to load options.
3. Firmware Update
Update firmware from .ADS file in storage. After firmware updated, the analyzer will be reboot.
2.5.1.6 Data and Time
Display the data and time On or Off. The system time is displayed in “ymd”, “mdy”, “dmy” format in
user interface.
2.5.1.7 Self Test
1. Screen Test
Test whether the screen has a dot defect using five colors: White, Red, Green, Blue and Black.
Press any key to switch the screen color and exit the test.
2. Keyboard Test
Enter the keyboard test interface. Press the function keys at the front panel one by one and
observe whether the corresponding key is checked. If not, an error may have occurred in that key.
To exit the test, press “<-“four times.
3. LCD Test
If the keys at the front panel are transparent, when the key is pressed, the corresponding backlight
will turn on when testing it.
2.5.2 Display
1. Display Line
Open or Close Display Line or move the location.
Table 2-38 Grid brightness
Parameter
Explanation
Default
0 dBm
Range
REF Level + REF Offset – 10*Scale/Div ~
REF Level + REF Offset
Knob Step
1 dB
Direction Key Step
10 B
2. Grid brightness

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
