SIGLENT SSA3021X User Manual

SIGLENT
SSA3000X User Manual 57
1. LAN
Config or reset related parameters of LAN. As default, the IP config is DHCP.
Figure 2-16 Static IP Config
2. GPIB
Config GPIB port number. The analyzer provides a USB-GPIB port on the front board.
2.5.1.4 Calibration
Auto Cal
When Auto Cal opens, the analyzer will process self-calibration regularly. Within half an hour after
power-on, the device executes a self-calibration every 10 minutes.
2.5.1.5 System Info
1. System Info
 Product Model, Serial and HOST ID
 Software Version and Hardware Version
 Option Information
Figure 2-17 System Info

SIGLENT SSA3021X Specifications

General

Frequency Range	9 kHz to 2.1 GHz
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Sweep Time	1 ms to 1000 s
Input Impedance	50 Ω
Input VSWR	< 1.5
Maximum Input Level	+30 dBm
Tracking Generator	Optional
Displayed Average Noise Level (DANL)	-161 dBm/Hz
Interfaces	USB Host, USB Device, LAN, GPIB (optional)
Display Resolution	1024 points
Power Requirements	100 V - 240 V AC, 50 Hz/60 Hz
Phase Noise	-98 dBc/Hz @ 10 kHz offset (1 GHz carrier)
