SCP 111
S-DIAS SAFETY CPU MODULE
Page
12
04.11.2020
2.3
Safety-Relevant
Parameters
2.3.1
Mounting Position Horizontal 0-55 °C Ambient Temperature
CPU Module
Safety Parame
ters
Safety Levels
SCP 011
PFH
D
= 1,4E-10 (
1/h)
MTTF
D
= 2689 years
DC = 99 %
SFF = 99 %
SIL 3
according to EN/IE
C 62061
PL e / Cat. 4
according to EN IS
O 13849-
1/
-2
Structure: Two-c
hannel redundant (divers
e)
2.3.2
Mounting Position Horizontal 55-60 °C Ambient Temperature
CPU Module
Safety Parame
ters
Safety Levels
SCP 011
PFH
D
= 1,7E-10 (
1/h)
MTTF
D
= 2243 years
DC = 99 %
SFF = 99 %
SIL 3
according to EN/IE
C 62061
PL e / Cat. 4
according to EN IS
O 13849-
1/
-2
Structure: Two-c
hannel redundant (d
iverse)
13
15
Table of Contents
Table of Contents
4
Basic Safety Guidelines
7
General Safety Information
7
Further Safety Guidelines
8
General Requirements
9
Safety Conformity
13
Functional Safety Standards
13
EU Conformity Declaration
13
Safety-Relevant Parameters
14
Mounting Position Horizontal 0-55 °C Ambient Temperature
14
Mounting Position Horizontal 55-60 °C Ambient Temperature
14
Compatibility
15
Technical Data
16
Performance Data
16
Electrical Requirements
16
Module Supply (Input)
16
S-DIAS Bus/Safety Supply (Output)
17
Miscellaneous
20
Environmental Conditions
20
Mechanical Dimensions
21
Connector Layout
22
Status Leds
23
Applicable Connectors
24
Label Field
25
Validation Button
26
Explanation of the Individual Sequences
26
Start Sequence
26
Command Selection Sequence
27
End Sequence
27
Error Sequence
28
Overview of Commands
29
Overview of Module Status and Commands
29
Handling the Microsd Card
31
Configuring a Safety CPU with the SD Card
32
Error Response
34
Restart Errors
34
Configuration Distribution Error
35
Troubleshooting
36
Troubleshooting with the Safetydesigner
36
Correcting a Wiring Error
36
Wiring Guidelines
37
Mounting
38
Supported Cycle Times
40
Cycle Times below 1 Ms (in Μs)
40
Cycle Times Equal to or Higher than 1 Ms (in Ms)
40
Disposal
40
Hardware Class SCP111
41
General
42
Safety
43
Communication Interfaces
45
Global Methods
46
Fetchdiagstate
46
Getdiagstate
46
Fetchdiaginfo
46
Getdiaginfo
46
Savelog
47
Savelogactive
47
Importance of Classstate and Safetystate
48
Example
48
Internal Properties
48
Transmission of Safe Signals over Several Machines or Machine Parts
49
When to Use Interface Connections and When to Use Flexcon
50
Interface Connection
51
Safety Hot Swap (Flexcon Connection)
56
